Harrick Praying Mantis 螳螂™高溫反應室 HVC-DRM-5 HVC-DRP-5 HVC-VUV-5 高溫高壓反應池 原位池

Harrick Praying Mantis 螳螂™ 高溫反應室對于具有高比表面積的粉末特別有效。這使得漫反射成為研究多相催化、氣固相互作用、光化學反應和氧化機制的有價值的工具。這種高溫反應室非常適合在精心控制的溫度和壓力下進行此類研究。高溫反應室應用允許在受控壓力和廣泛溫度下進行漫反射（漂移）光譜測量。它和螳螂一起使用™ 紅外光譜和紫外-可見漫反射光譜的附件。也可用于拉曼光譜。

特征
設計用于從高真空（133μPa或10-6torr）到133kpa（1ktorr），帶KBr窗口或1.5mpa（11.3ktorr）帶ZnSe窗口的操作。
達到910°C的溫度（在真空下）。
易于適應高達3.44MPa（25.8ktorr）的操作，帶有可選的高壓圓頂。
提供三個入口/出口，用于排空電池和引入氣體。
由耐化學腐蝕的316不銹鋼制成。
可選的Silcotek/Restek惰性涂層可提高惰性和耐腐蝕性。
可選的冷卻筒可用于中等程度的冷卻或加熱，帶有冷卻器或再循環裝置。
可用于顯微光譜應用的替代窗口組件，包括拉曼。
包括
反應室。
低壓加熱筒。
K型熱電偶。
樣品包裝工具和溢液盤。
帶有兩個KBr或ZnSe窗口和一個玻璃觀察窗口（FTIR配置）的圓頂。
帶有兩個SiO2窗口和一個玻璃觀察窗口（UV-Vis-NIR配置）的圓頂。
相關配件：
MODEL NO.NAMEDESCRIPTION
ATK-024-3Temperature Controller, 110VTemperature Controller (110V) with USB to RS-485 Adapter
ATK-024-4Temperature Controller, 220/240VTemperature Controller (220/240V) with USB to RS-485 Adapter
CHC-CHA-3Praying Mantis™ Low Temperature Reaction Chambers (FTIR)Praying Mantis™ diffuse reflection environmental chamber, 24V
CHC-VUV-3Praying Mantis™ Low Temperature Reaction Chambers (UV-Vis-NIR)Praying Mantis™ diffuse reflection environmental chamber, 24V
DRK-3-XXXDiffuse Reflection Catalysis Package, 110VKit with Praying Mantis, Reaction Chamber, Controller, etc.
DRK-4-XXXDiffuse Reflection Catalysis Package, 220VKit with Praying Mantis, Reaction Chamber, Controller, etc.
DRP-XXXPraying Mantis™ Diffuse Reflection AccessoryDiffuse reflection accessory



MODEL NO.NAME
007-085VCO to Swagelok Adapter (English)
116-998VCO to Swagelok Adapter (Metric)
DRP-ASCAmbient Chamber (FTIR) for Praying Mantis
DRP-ASC-VUVAmbient Chamber (UV-Vis-NIR) for Praying Mantis
DRP-PDRPraying Mantis Purge Shield
HVC-COLHVC Cooling Cartridge
HVC-DWA-2Standard Reaction Chamber Dome, SiO?
HVC-DWA-3High Press. Dome, SiO?, for High Temp. Chamber
HVC-DWI-2Standard Reaction Chamber Dome, ZnS
HVC-DWI-3High Press. Dome, ZnS, for High Temp. Chamber
HVC-DWM-2Standard Reaction Chamber Dome, ZnSe
HVC-DWM-3High Press. Dome, ZnSe, for High Temp. Chamber
HVC-DWP-2Standard Reaction Chamber Dome, KBr
HVC-MRAStandard Reaction Chamber Raman Assembly, SiO?

易耗配件：

MODEL NO.NAME
008-144Thermocouple, K-Type
116-439Screen Set (2 each of the three sizes), 6.3 mm dia.
116-439-1SScreen Set (6), pore size 0.104 mm (0.0041″), 6.3 mm dia.
116-439-2SScreen Set (6), pore size 0.061 mm (0.0024″), 6.3 mm dia.
116-439-3SScreen Set (6), pore size 0.038 mm (0.0015″), 6.3 mm dia.
HVC-CERCeramic Filters (4, 80um max. pore dia), 6.3 mm dia.
KIT-SCPSpatula/Scoopula
Gaskets
MODEL NO.NAME
116-429PTFE Washer, OD 0.59″ (15mm)
Heaters
MODEL NO.NAME
HTRS-26Cartridge Heater, 0.25″ x 1.24″, 24V/100W
Heater Assembly for High Temp. Reaction Chambers
O-Rings
MODEL NO.NAME
HVC-ORKKalrez O-Rings for High Temp. Reaction Chambers
HVC-ORVViton O-Rings for High Temp. Reaction Chambers
ORK-010Kalrez O-Ring, 0.379 OD, 0.239 ID
ORK-013Kalrez O-Ring, 0.566 OD, 0.426 ID
ORK-016Kalrez O-Ring, 0.754 OD, 0.614 ID
ORK-023Kalrez O-Ring, 1.191 OD, 1.051 ID
ORV-010Viton O-Ring, 0.379 OD, 0.239 ID
ORV-013Viton O-Ring, 0.566 OD (15 mm), 0.426 ID
ORV-016Viton O-Ring, 0.754 OD, 0.614 ID
ORV-023Viton O-Ring, 1.191 OD, 1.051 ID
Reference & Mirrors
MODEL NO.NAME
KBR-100KBr Powder, Spectroscopic Grade, 100 g
Windows
MODEL NO.NAME
WAD-U23Window SiO? 15 x 2 mm
WAD-U43Window SiO? 15 x 4 mm
WED-U23Window Si 15 x 2 mm
WFD-U23Window CaF? 15 x 2 mm
WHD-U23Window BaF? 15 x 2 mm
WID-U43Window ZnS 15 x 4 mm
WJD-U23Window Ge 15 x 2 mm
WLD-U23Window NaCl 15 x 2 mm
WMD-U23Window ZnSe 15 x 2 mm
WMD-U43Window ZnSe 15 x 4 mm
WPD-U23Window KBr 15 x 2 mm
